Gigabyte GA-K8NF-9 (rev. 1.x)
Logs
chipChipset
cpuSocket
Socket 939 (mPGA939)
speedFSB speeds
800MHz1000MHz
moboForm factor
ATX (max 305 x 244 mm)
dimDimensions
305mm x 244mm
chipCache
None/Integrated in the CPU
ramMax RAM size
4GB(DDR-400)
ramRAM type
DDR UDIMM
pwrPSU connector
ATX 2.x (24-pin ATX) ATX P4 connector 12v (4-pin P4)
tag Also known as
connI/O ports
1x
3.5mm Audio Combo
3x
FireWire 800
1x
Floppy interface
2x
IDE interface
1x
IrDA
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
1x
RJ-45 LAN
1x
S/PDIF
4x
SATA I
1x
Serial
10x
USB 2.0
cardExpansion slots
3x
32-bit PCI
2x
PCIe x1
1x
PCIe x16
wrench Known issues
  • Faulty or Leaking Electrolytic Capacitors

Some motherboards may contain faulty or leaking electrolytic capacitors, which can negatively impact system performance or stability. These capacitors may exhibit issues such as bulging, leaking, or even exploding, potentially damaging other components on the motherboard. Users should inspect their capacitors regularly and replace any that are faulty or leaking to avoid damage or system instability.

notes Notes

  • Despite having 24-Pin ATX 2.x power connector, board is by default intended for and fully functional with 20-Pin ATX power supplies.

  • Has NICHICON HM series capacitors which are known to have faulty batches. They should be checked.

Last updated 2025-10-29T09:33:36Z
Board info score is 9.8/10
bios 8 BIOS files available

vendor Award - 8 entries

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
10/27/2005-NF-CK804-6A61FG0AC-00
Note
Core version
6.00PG
BIOS version
Logs
POST string
10/13/2005-NF-CK804-6A61FG0AC-00
Note
Core version
6.00PG
BIOS version
Logs
POST string
05/02/2005-NF-CK804-6A61FG0AC-00
Note
Core version
6.00PG
BIOS version
Logs
POST string
04/07/2005-NF-CK804-6A61FG0AC-00
Note
Core version
6.00PG
BIOS version
Logs
POST string
12/17/2004-NF-CK804-6A61FG0AC-00
Note
Core version
6.00PG
BIOS version
Logs
POST string
10/22/2008-NF-CK804-6A61FG0AC-00
Note
Core version
6.00PG
BIOS version
Logs
POST string
01/13/2006-NF-CK804-6A61FG0AC-00
Note
Core version
6.00PG
BIOS version
Logs
POST string
12/05/2005-NF-CK804-6A61FG0AC-00
Note
Core version
6.00PG
BIOS version
Logs
drv 8 drivers available
Name
Version
OS support
Arch
Size
Filename
Name
Version
1.0
OS support
Windows 2000 Windows NT 4.0
Arch
x86
Size
1.4MB
Filename
Name
Version
1.0
OS support
Windows 2000 Windows NT 4.0
Arch
x86-64
Size
819.6KB
Filename
Name
Version
A4.06
OS support
Windows 2000 Windows XP/2k3
Arch
x86
Size
17.9MB
Filename
Version
OS support
Arch
Size
Filename
Version
OS support
Windows 2000 Windows XP/2k3
Arch
x86
Size
37.8MB
Filename
Version
OS support
Windows XP/2k3
Arch
x86
Size
50.9MB
Filename
Version
OS support
Arch
Size
Filename
Version
OS support
Windows 9x
Arch
x86
Size
19KB
Filename
Version
OS support
Windows NT 4.0
Arch
x86
Size
16.5KB
Filename
Version
OS support
Windows 2000
Arch
x86
Size
31.9KB
Filename
doc 1 board document available
Release date
File
Logs
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
2000-02-29
File
Logs
Chip
Release date
2003-09-12
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
2002-12
File
Logs
Chip
Release date
2006-09
File
Logs
Chip
Release date
2004-09-24
File
Logs
image1 Image 1 of 7 (Gigabyte)
image2 Image 2 of 7 (Gigabyte)
image3 Image 3 of 7 (Eric Voirin (oerg866))
image4 Image 4 of 7 (CircusCat)
image5 Image 5 of 7 (Eric Voirin (oerg866))
image6 Image 6 of 7 (CircusCat)
image7 Image 7 of 7 (Gigabyte)
