PCChips/Hsin Tech M571 V1.3
Chipset
Socket
FSB speeds 60MHz66MHz
Form factorBaby AT (max 220 x 330 mm)
Dimensions330mm x 218mm
Max VRAM size2MB
Cache
256KB512KB
Max RAM size
512MB
RAM types 72-pin EDOSDR UDIMM168-pin EDO UDIMM
PSU connector
I/O ports1x
AT Keyboard
1x
Floppy interface
1x
Gameport
2x
IDE interface
1x
PS/2 mouse
1x
Parallel
2x
Serial
2x
USB 1.x
1x
VGA
Expansion slots4x
16-bit ISA
4x
32-bit PCI
Last updated 2025-02-20T14:34:56Z
Board info score is 8.7/10
Chips
3 BIOS files available
Award - 1 entry
POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
Note
Core version
BIOS version
Logs
AMI - 4 entries
POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
51-0506-001437-00101111-071595-M571-007_66_M571
Note
Core version
071595
BIOS version
Logs
POST string
51-0423-001437-00111110-071595-M571-007_66_M571
Note
Core version
071595
BIOS version
Logs
POST string
51-0514-001437-00101111-071595-M571-007_66_M571
Note
Core version
071595
BIOS version
Logs
POST string
51-0224-001437-00111111-071595-571-007_66_571-H
Note
Core version
071595
BIOS version
Logs
8 drivers available
Name
Version
OS support
Arch
Size
Filename
Name
Version
4.10.0.00152
OS support
Windows 9x
Windows NT 4.0
Arch
Size
35.9MB
Filename
Name
Version
4.10.00.0152
OS support
MS-DOS
Windows 3.1x
Windows 9x
Windows NT 4.0
Arch
Size
27.2MB
Filename
Name
Version
1.13
OS support
Windows 2000
Windows 9x
Windows NT 3.5x
Windows NT 4.0
Arch
Size
Empty
Filename
Name
Version
2.04A
OS support
Windows 2000
Windows 9x
Windows XP/2k3
Arch
Size
Empty
Filename
Name
Version
2.13
OS support
MS-DOS
OS/2 Warp 3.x
OS/2 Warp 4.x
Windows 9x
Windows NT 3.1
Windows NT 3.5x
Windows NT 4.0
Arch
Size
Empty
Filename
Version
OS support
Arch
Size
Filename
4 board documents available
Release date
File
Logs
Chip
Release date
File
Logs
Family
Release date
File
Logs
Family
Release date
1998-01
File
Logs
Image 1 of 1 (Microhouse)
