Advantech POS-562
Chipset
Socket
FSB speeds 50MHz60MHz66MHz
Form factorMini LPX (max 229 x 279 mm)
Dimensions220mm x 235mm
Max VRAM size4MB
Cache
512KB
Max RAM size
128MB
RAM types 72-pin FPM72-pin EDOSDR UDIMM
PSU connector
Also known as
- Advantech POS-562L (No audio)
I/O ports1x
Floppy interface
2x
IDE interface
1x
IrDA
1x
LVDS
1x
PS/2 KB+MS Combo
2x
PS/2 keyboard
2x
Parallel
1x
RJ-45 LAN
4x
Serial
2x
USB 1.x
1x
VGA
Expansion slots1x
PISA
Known issues
- Expansion slots are on proprietary riser
The listed slots are on the riser card that came with the motherboard.
If you have this board make sure you have the riser for it.
Last updated 2026-01-05T23:25:29Z
Board info score is 7.2/10
Chips
-> Chipset part
-> Audio
-> Network
-> Signal transmitter/receiver
-> Super I/O
-> Video
0 BIOS files available
6 drivers available
Name
Version
OS support
Arch
Size
Filename
Name
Version
5.719.0325.2009
OS support
Linux
MS-DOS
Mac OS X
NetWare Server 3
NetWare Server 4
Windows 2000
Windows 7
Windows 9x
Windows Vista
Windows XP/2k3
Arch
x86
Size
39.5MB
Filename
Name
Version
V5.00
OS support
MS-DOS
Mac OS X
NetWare Server 3
NetWare Server 4
Netware Client32
SCO Unix - OpenServer
Windows 2000
Windows 3.1x
Windows 9x
Windows NT 3.5x
Windows NT 4.0
Arch
x86
, PPC
Size
3.3MB
Filename
Name
Version
2.13
OS support
MS-DOS
OS/2 Warp 3.x
OS/2 Warp 4.x
Windows 9x
Windows NT 3.1
Windows NT 3.5x
Windows NT 4.0
Arch
Size
Empty
Filename
Version
OS support
Arch
Size
Filename
1 board document available
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
2007-11
File
Logs
Family
Release date
File
Logs
Family
Release date
1998-01
File
Logs
Image 1 of 1 (Advantech)
