[Unknown] D1581Q3A Ver: 1.0
Logs
Chipset
Socket
FSB speed Empty
Form factormicroATX (max 244 x 244 mm)
Dimensions244mm x 185mm
Cache
None/Integrated in the CPU
Max RAM size
64GB
RAM type DDR3 UDIMM
PSU connector
Also known as
- HSGM/Vulcan Revolution D1581-Q3A (D1581Q3A Ver: 1.0)
I/O ports1x
3.5mm Audio Combo
3x
RJ-45 LAN
6x
SATA III
1x
Serial
5x
USB 2.0
4x
USB 3.0
1x
VGA
Expansion slots2x
M.2 (M key)
1x
PCIe x16
1x
PCIe x4
1x
PCIe x8
Last updated 2025-09-04T18:49:06Z
Board info score is 5.1/10
Chips
-> Remote Management Processor
CPU family support
0 BIOS files available
No drivers available
No board documents available
Image 1 of 1 (HSGM/Vulcan Revolution)
