Sun SPARCengine Ultra AXi
Logs
chipChipset
cpuSocket
SUN IIi SME Module (180/120 Socket)
speedFSB speeds
90MHz100MHz111MHz120MHz
moboForm factor
ATX (max 305 x 244 mm)
dimDimensions
Empty
ramMax VRAM size
4MB
chipCache
None/Integrated in the CPU
ramMax RAM size
1GB(4x 256MB Double Stack DIMM's)
ramRAM types
168-pin EDO UDIMM168-pin EDO RDIMM
pwrPSU connector
ATX 1.x (20-pin ATX)
connI/O ports
1x
External SCSI
1x
Floppy interface
1x
Internal SCSI
1x
Parallel
1x
RJ-45 LAN
1x
SUN KB+MS
1x
Serial
cardExpansion slots
6x
64-bit PCI
1x
UPA64
notes Notes

Note! Some steppings might require updated BIOS/microcode to work properly.
Specific mainboard revisions require specific processor cards in combination with compatible processors to function. There are headers on the board for a PS/2 mouse and PS/2 keyboard

Last updated 2024-12-01T14:32:37Z
Board info score is 8.9/10
bios 0 BIOS files available

vendor Sun - 1 entry

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
106121-18
Note
Open
Core version
BIOS version
3.31
Logs
drv 5 drivers available
Name
Version
OS support
Arch
Size
Filename
Name
Version
4.0
OS support
MS-DOS
Arch
x86
Size
363.7KB
Filename
Name
Version
4.0
OS support
Windows 3.1x
Arch
x86
Size
402.3KB
Filename
Name
Version
4.13
OS support
Windows 9x
Arch
x86
Size
35.3KB
Filename
Name
Version
4.13
OS support
Windows NT 3.5x Windows NT 4.0
Arch
x86
Size
100.8KB
Filename
Name
Version
4.13
OS support
Windows NT 3.5x Windows NT 4.0
Arch
ALPHA
Size
46KB
Filename
image1 Image 1 of 4 (evasive)
image2 Image 2 of 4 (kazeobi)
image3 Image 3 of 4 (kazeobi)
image4 Image 4 of 4 (kazeobi)

Disclaimer

The info found in this page might not be entirely correct. Check out this guide to learn how you can improve it.
