PCPartner APPBS1-939 (35-8927-XX)/ APPBS1-C939 (35-C927-XX) with 596B SB
Logs
chipChipset
cpuSocket
Slot 1 (Slot-242)
speedFSB speed
Empty
moboForm factor
Baby AT (max 220 x 330 mm)
dimDimensions
Empty
chipCache
None/Integrated in the CPU
ramMax RAM size
256MB(unregistered SDRAM)512MB(registered SDRAM)
ramRAM type
SDR UDIMM
pwrPSU connector
ATX 1.x (20-pin ATX) AT (6-pin P8 + 6-pin P9)
tag Also known as
connI/O ports
1x
AT Keyboard
1x
Floppy interface
2x
IDE interface
1x
PS/2 mouse
1x
Parallel
2x
Serial
2x
USB 1.x
cardExpansion slots
2x
16-bit ISA
1x
3.3V AGP
3x
32-bit PCI
Last updated 2023-01-16T23:21:42Z
Board info score is 8.2/10
bios 1 BIOS file available

vendor Award - 1 entry

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
10/09/2000-693-596B-8671-2A6LGV3DC-00
Note
Core version
4.51PG
BIOS version
Logs
drv 3 drivers available
Name
Version
OS support
Arch
Size
Filename
Name
Version
1.12.000
OS support
Windows 9x
Arch
x86
Size
841.8KB
Filename
Name
Version
N/A
OS support
Windows 3.1x Windows 9x Windows NT 3.5x Windows NT 4.0
Arch
x86
Size
14.6MB
Filename
Name
Version
4.43V
OS support
Windows 2000 Windows 9x Windows NT 4.0 Windows XP/2k3
Arch
Size
1.1MB
Filename
doc 1 board document available
Release date
File
Logs
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
1999-06-17
File
Logs
Chip
Release date
1998-12-09
File
Logs
Family
Release date
File
Logs
Family
Release date
1998-01
File
Logs
Socket
Release date
File
Logs
Socket
Release date
1999-02
File
Logs
Socket
Release date
1997-05
File
Logs
image1 Image 1 of 1 (PcPartner)

Disclaimer

The info found in this page might not be entirely correct. Check out this guide to learn how you can improve it.
