JGINYUE X99M PLUS-V2
Logs
chipChipset
cpuSocket
speedFSB speed
Empty
moboForm factor
microATX (max 244 x 244 mm)
dimDimensions
235mm x 185mm
chipCache
None/Integrated in the CPU
ramMax RAM size
32GB
ramRAM types
DDR3 UDIMMDDR4 UDIMMDDR3 UDIMM ECCDDR4 UDIMM ECC
pwrPSU connector
connI/O ports
1x
3.5mm Audio Combo
1x
PS/2 keyboard
1x
PS/2 mouse
1x
RJ-45 LAN
2x
SATA II
2x
SATA III
8x
USB 2.0
4x
USB 3.0
cardExpansion slots
1x
M.2 (E key)
2x
M.2 (M key)
2x
PCIe x1
1x
PCIe x16
wrench Known issues
  • Falsely advertised chipset

This motherboard uses a different chipset than the one advertised by the vendor. In most cases, a lower tier chipset was used in order to save costs. It is likely that the board may not have the same levels of performance as one equipped with genuine parts.

Beware that issues regarding BIOS and driver compatibility may arise as well, so double check with any hardware reporting software what chipset is actually installed on the board before proceeding any further.

Last updated 2025-09-04T04:58:25Z
Board info score is 6.5/10
bios 0 BIOS files available
drv 2 drivers available
Name
Version
OS support
Arch
Size
Filename
Name
Version
5.0.4.43v2
OS support
Windows 7
Arch
Size
5.3MB
Filename
Name
Version
R2.74
OS support
Windows 2000 Windows 7 Windows Vista Windows XP/2k3
Arch
Size
30.7MB
Filename

Disclaimer

The info found in this page might not be entirely correct. Check out this guide to learn how you can improve it.
