Intel Premiere/PCI LP/LPX (Robin ACE)
Chipset
Socket
FSB speed 60MHz
Form factorLPX (max 229 x 330 mm)
Dimensions330mm x 218mm
Max VRAM size1MB
Cache
256KB
Max RAM size
128MB
RAM types 72-pin FPM72-pin EDO
PSU connector
Also known as
- IBM PS/ValuePoint 6384 D/P60
I/O ports1x
Floppy interface
2x
IDE interface
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
2x
Serial
1x
VGA
Expansion slots1x
16-bit ISA
2x
32-bit PCI
Known issues
- Expansion slots are on proprietary riser
The listed slots are on the riser card that came with the motherboard.
If you have this board make sure you have the riser for it.
- Faulty IDE Controller
The IDE controller(s) is known to be faulty, which may cause problems with IDE devices such as data corruption or lockups.
Notes
expansion slots on riser card
Last updated 2025-06-24T18:49:55Z
Board info score is 8.7/10
Chips
-> Chipset part
-> IDE ctrl.
-> Video
CPU family support
10 drivers available
Name
Version
OS support
Arch
Size
Filename
Name
Version
August 27, 1991
OS support
Windows 3.0
Arch
x86
Size
256.8KB
Filename
Name
Version
N/A
OS support
Windows NT 3.1
Arch
x86
Size
75.6KB
Filename
Name
Version
2.60
OS support
MS-DOS
OS/2 2.x
OS/2 Warp 3.x
Windows 3.1x
Arch
x86
Size
2.7MB
Filename
Name
Version
1992-04-06
OS support
Windows 3.1x
Arch
x86
Size
221.8KB
Filename
Name
Version
1992-04-15
OS support
Windows 3.1x
Arch
x86
Size
228.1KB
Filename
Name
Version
1992-04-03
OS support
Windows 3.1x
Arch
x86
Size
705.8KB
Filename
Version
OS support
Arch
Size
Filename
Version
OS support
Arch
Size
Filename
1 board document available
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Family
Release date
File
Logs
1 other file available
Title
File
Logs
Image 1 of 1 (evasive)
