DFI CB60-V3
Logs
chipChipset
cpuSocket
Socket 370 (PGA370)
speedFSB speeds
66MHz100MHz
moboForm factor
ATX (max 305 x 244 mm)
dimDimensions
Empty
chipCache
None/Integrated in the CPU
ramMax RAM size
384MB(unbuffered)
ramRAM type
SDR UDIMM
pwrPSU connector
ATX 1.x (20-pin ATX)
connI/O ports
1x
Floppy interface
2x
IDE interface
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
2x
Serial
1x
USB 1.x
cardExpansion slots
3x
16-bit ISA
1x
3.3V AGP
4x
32-bit PCI
notes Notes

Celeron 500 only on Rev G or higher.

Last updated 2022-08-01T14:25:29Z
Board info score is 8.3/10
bios 3 BIOS files available

vendor Award - 3 entries

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
09/13/1999-693-596A-CD-2A6LGD4FC-00
Note
Core version
4.51PG
BIOS version
Logs
POST string
04/16/1999-693-596A-BD-2A6LGD4FC-00
Note
Core version
4.51PG
BIOS version
Logs
POST string
06/23/1999-693-596A-BD-2A6LGD4FC-00
Note
Core version
4.51PG
BIOS version
Logs
drv 2 drivers available
Name
Version
OS support
Arch
Size
Filename
Name
Version
N/A
OS support
Windows 2000 Windows 9x Windows NT 4.0
Arch
Size
Empty
Filename
Name
Version
4.43V
OS support
Windows 2000 Windows 9x Windows NT 4.0 Windows XP/2k3
Arch
Size
1.1MB
Filename
doc 3 board documents available
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
1998-12-09
File
Logs
Chip
Release date
1998-12-09
File
Logs
Family
Release date
File
Logs
Family
Release date
2002-02
File
Logs
Socket
Release date
File
Logs
Socket
Release date
1997-05
File
Logs
Socket
Release date
File
Logs
Socket
Release date
1999-04
File
Logs
Socket
Release date
1999-12
File
Logs
Socket
Release date
2000-07
File
Logs
image1 Image 1 of 1 (evasive)

Disclaimer

The info found in this page might not be entirely correct. Check out this guide to learn how you can improve it.
