Dell OmniPlex 4XX/MX(V), OmniPlex 4XXS/MX(V), OmniPlex 4XX/L(V)
Logs
Chipset
Socket Empty
FSB speeds 25MHz33MHz50MHz
Form factorLPX (max 229 x 330 mm)
Dimensions330mm x 218mm
Max VRAM size1MB
RAM type
PSU connector
I/O ports1x
Floppy interface
1x
IDE interface
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
2x
Serial
1x
VGA
Expansion slots1x
32-bit VLB
Known issues
- Expansion slots are on proprietary riser
The listed slots are on the riser card that came with the motherboard.
If you have this board make sure you have the riser for it.
Notes
Even though there are 2 physical slots on the optional VESA riser card, only 1 VESA card is supported in this system due to power considerations. REV B has ET4000W32i onboard VGA
Last updated 2025-06-24T17:43:27Z
Board info score is 6.7/10
Chips
CPU family support
0 BIOS files available
14 drivers available
Name
Version
OS support
Arch
Size
Filename
Name
Version
N/A
OS support
Windows 3.1x
Arch
x86
Size
624.8KB
Filename
Name
Version
1992-01-15
OS support
Windows 3.0
Windows 3.1x
Arch
x86
Size
504.9KB
Filename
Name
Version
1991-10-29
OS support
Windows 3.1x
Arch
x86
Size
397.5KB
Filename
Name
Version
1991-12-06
OS support
Windows 3.0
Windows 3.1x
Arch
x86
Size
399.3KB
Filename
Name
Version
4.0.953
OS support
Windows 9x
Arch
x86
Size
18.4KB
Filename
Version
OS support
Arch
Size
Filename
1 board document available
Release date
File
Logs
Chip
Release date
File
Logs
Family
Release date
File
Logs
Image 1 of 1 (Microhouse)
Disclaimer
The info found in this page might not be entirely correct. Check out this guide to learn how you can improve it.
