AMI 386XT (s4)

Description

Chips

BIOS 1

Drivers 0

Documentation 1

Logs

Chipset

(multiple brand) Discrete Logic w C&T CS8220

Sockets

FSB speeds

16MHz20MHz

Form factor

Baby AT (max 220 x 330 mm)

Dimensions

330mm x 218mm

Cache

64KB

Max RAM size

4MB

RAM type

DIP-16 (1bit)

PSU connector

Empty

Also known as

Atari PC5 C300394 Rev 2
AMPEX SL-386

I/O ports

AT Keyboard

Expansion slots

16-bit ISA

8-bit ISA

Last updated 2025-11-26T20:34:26Z

Board info score is 7.2/10

Chips

-> Chipset part

CHIPS and Technologies 82A203 (High Address Buffer) CHIPS and Technologies 82A204 (Low Address Buffer) (multiple brand) Discrete Logic

CPU family support

386DX
387DX

0 BIOS files available

AMI - 1 entry

POST string

Note

Core Ver.

BIOS Ver.

Logs

POST string

Note

Core version

BIOS version

Logs

No drivers available

1 board document available

Release date

File

Logs

Release date

File

User Manual

Logs

Image 1 of 5 (Atari PC)

Image 2 of 5 (Atari PC)

Image 3 of 5 (oldpcstore)

Image 4 of 5

Image 5 of 5
