Acer V55LA-2
Logs
chipChipset
cpuSocket
Socket 7 (PGA321)
speedFSB speeds
50MHz60MHz66MHz
moboForm factor
LPX (max 229 x 330 mm)
dimDimensions
254mm x 218mm
ramMax VRAM size
2MB
chipCache
256KB512KB1MB
ramMax RAM size
128MB
ramRAM types
72-pin FPM72-pin EDO
pwrPSU connector
Empty
tag Also known as
connI/O ports
1x
Floppy interface
2x
IDE interface
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
2x
Serial
2x
USB 1.x
1x
VGA
cardExpansion slots
1x
PISA
wrench Known issues
  • Expansion slots are on proprietary riser

The listed slots are on the riser card that came with the motherboard.
If you have this board make sure you have the riser for it.

Last updated 2025-06-24T20:12:53Z
Board info score is 8.2/10
bios 5 BIOS files available

vendor Acer - 5 entries

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
ACR4BE00-M11-971204-R03-B1 S0
Note
Core version
V2.1
BIOS version
Logs
POST string
ACR4BE00-M11-970709-R03-A2 TEST1
Note
Core version
V2.1
BIOS version
Logs
POST string
ACR4BE00-M11-971226-R03-A2
Note
Core version
V2.1
BIOS version
Logs
POST string
ACR4BE00-M11-970331-R03-A2
Note
Core version
V2.1
BIOS version
Logs
POST string
ACR4BE00-M11-970328-R03-A1 S1
Note
Core version
V2.1
BIOS version
Logs
drv 2 drivers available
Version
OS support
Arch
Size
Filename
Version
OS support
Windows 9x
Arch
x86
Size
1.6MB
Filename
Version
OS support
Windows 9x
Arch
x86
Size
517KB
Filename
doc 3 board documents available
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
1996
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Family
Release date
File
Logs
Family
Release date
1997-06
File
Logs
Family
Release date
1998-01
File
Logs
image1 Image 1 of 1 (Microhouse)

Disclaimer

The info found in this page might not be entirely correct. Check out this guide to learn how you can improve it.
