Acer MPF-PC/1100-16/20
Logs
chipChipset
cpuSockets
PGA132 PGA68
speedFSB speeds
16MHz20MHz25MHz
moboForm factor
AT (max 305 x 330 mm)
dimDimensions
330mm x 218mm
chipCache
None/Integrated in the CPU
ramMax RAM size
8MB
ramRAM type
Empty
pwrPSU connector
Empty
tag Also known as
connI/O ports
1x
AT Keyboard
cardExpansion slots
5x
16-bit ISA
2x
8-bit ISA
notes Notes

proprietary memory card slot for up to 8MB RAM.

Last updated 2025-09-20T09:12:49Z
Board info score is 7.2/10
chip Chips
-> Chipset part
(multiple brand) Discrete Logic
cpufam CPU family support
bios 2 BIOS files available

vendor Award - 2 entries

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
BIOS 3.01A 07/01/1987
Note
U43 (odd byte)
Core version
2.20
BIOS version
Logs
POST string
BIOS 3.01A 07/01/1987
Note
U41 (even byte)
Core version
2.20
BIOS version
Logs
drv No drivers available
doc 1 board document available
Release date
File
Logs
Release date
File
Logs
image1 Image 1 of 1 (Microhouse)

Disclaimer

The info found in this page might not be entirely correct. Check out this guide to learn how you can improve it.
