Western Digital Verticom H16 HPG
Logs
typeType
Video
interfaceInterface
signalSignaling
8-bit ISA
datePCI ID
Empty
chip Chips and specs
-> Processor
Motorola MC68000
-> RAMDAC
STMicroelectronics / Inmos IMSG176 (Palette DAC)
-> Video
NEC uPD7220A (multiple brand) 82C431 (Graphics Controller) (multiple brand) 82C432 (Sequencer) (multiple brand) 82C433 (Attributes Controller) (multiple brand) 82C434 (CRT Controller)
Microarchitecture
CPUID
Process node 3500nm
Core
Bus speed 10MHz
Frequency 10MHz
Multiplier 1x
Power
Voltage
portintI/O ports
2x
  • DE-9
powerPower connectors
Empty
notes Notes
  • This card is 3 boards together in one big sandwich
  • Developed by Verticom before the Western Digital Merger
