Miro miroCRYSTAL 20SD TWIN/PCI
Logs
typeType
Video
interfaceInterface
signalSignaling
32-bit PCI
dimSlot height
1
datePCI ID
8880 8881 8882 8883
fccFCC ID
LAHC20TW-PCI-1
ramRAM size
4MB
chip Chips and specs
-> Clock Synth / PLL
ICDesigns 2061A (Graphics Clock Generator)
-> RAMDAC
AT&T 21C498 (PrecisionDAC)
-> Video
S3 86C868 (Vision868)
MTL
Category Video
Memory Type DRAM
Data Bus Type 32-bit PCI
Video Processor S3 Vision864
Video Types Supported XVGA
Maximum Onboard Memory 2MB (4MB when daughter board is installed)
Highest Resolution Supported 1408 x 1024
portintI/O ports
1x
  • 2x13 2.54mm pin header
2x
  • DE-15
powerPower connectors
Empty
Last updated 2025-10-17T21:39:25Z
biosc No BIOS files available
drv 4 drivers available
Name
Version
OS support
Arch
Size
Filename
Name
Version
N/A
OS support
MS-DOS Windows 3.1x Windows 9x Windows NT 3.1 Windows NT 3.5x
Arch
x86
Size
895KB
Filename
Name
Version
2.01.09
OS support
Windows 9x
Arch
x86
Size
124.2KB
Filename
Name
Version
N/A
OS support
Windows NT 3.5x
Arch
x86
Size
64.6KB
Filename
Name
Version
2.00.18
OS support
Windows NT 4.0
Arch
x86
Size
177.7KB
Filename
doc 2 card documents available
Release date
File
Logs
Release date
File
Logs
Release date
1999
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
image1 Image 1 of 7 (Microhouse)
image2 Image 2 of 7 (Palcal)
image3 Image 3 of 7 (Palcal)
image4 Image 4 of 7 (Palcal)
image5 Image 5 of 7 (Palcal)
image6 Image 6 of 7 (Palcal)
image7 Image 7 of 7 (Microhouse)
