ATi GRAPHICS ULTRA (Mach 8, No Mouse, VM1)
Logs
typeType
Video
interfaceInterface
signalSignaling
16-bit ISA
dimSlot height
1
datePCI ID
Empty
fccFCC ID
EXMCOMBOVM1
ramRAM type
VRAM
ramRAM size
512KB1MB
chip Chips and specs
-> RAMDAC
Samsung KDA0476 (CMOS RAMDAC)
-> Video
ATi 38800-1 (mach8) ATi 28800-6 (VGA 1024D)
MTL
Data Bus 8/16-bit ISA
Card Type Video card
Video Chip Set ATI
Maximum Video Memory 512 VRAM
Video Types Supported XVGA
Highest Resolution Supported 1280 x 1024
tag Also known as
  • ATi 10911550 / 109-00115-50 / 109115541
  • ATi VGA Wonder GT
portintI/O ports
1x
  • DE-15
powerPower connectors
Empty
Last updated 2025-12-10T22:21:32Z
biosc No BIOS files available
drv 8 drivers available
Name
Version
OS support
Arch
Size
Filename
Name
Version
August 27, 1991
OS support
Windows 3.0
Arch
x86
Size
256.8KB
Filename
Name
Version
1992-04-06
OS support
Windows 3.1x
Arch
x86
Size
221.8KB
Filename
Name
Version
1992-04-15
OS support
Windows 3.1x
Arch
x86
Size
228.1KB
Filename
Name
Version
1992-04-03
OS support
Windows 3.1x
Arch
x86
Size
705.8KB
Filename
Version
OS support
Arch
Size
Filename
Version
OS support
Windows 3.1x
Arch
x86
Size
923.8KB
Filename
Version
OS support
Windows 3.1x
Arch
x86
Size
754.7KB
Filename
Version
OS support
Arch
Size
Filename
Version
OS support
Windows 3.1x
Arch
x86
Size
216.7KB
Filename
Version
OS support
Windows 3.1x
Arch
x86
Size
528.4KB
Filename
doc 1 card document available
Release date
File
Logs
Release date
1999
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
image1 Image 1 of 3 (Microhouse)
image2 Image 2 of 3 (Palcal)
image3 Image 3 of 3 (Palcal)
