AST ADVANTAGE! MEMORY EXPANSION AND I/O BOARD
Logs
Interface
Signaling
PCI IDEmpty
RAM type DRAM
RAM size
3MB
Chips and specs
-> UART ctrl.
| MTL | |
|---|---|
| Chip Set | Unidentified |
| Data Bus | 16-bit ISA |
| Card Type | Multi-I/O card |
| I/O Options | Game port, parallel port, serial ports (2), Advantage-Pak memory card |
| Maximum Onboard Memory | 3MB DRAM (with daughter board) |
| Floppy drives supported | None |
I/O ports
1x
- 2x8 2.54mm pin header
1x
- DB-25
1x
- DE-9
1x
- 2x5 2.54mm pin header
Power connectorsEmpty
Last updated 2025-06-17T18:09:15Z
No BIOS files available
No drivers available
8 card documents available
Release date
File
Logs
Chip
Release date
File
Logs
Image 1 of 4 (Microhouse)
Image 2 of 4 (JRC)
Image 3 of 4 (JRC)
Image 4 of 4 (Microhouse)
